Distance: Table – sleeve w / o chuck max. / min.
550 / 240 mm (optional 615 / 305 mm)
Dielectric fluid above table
365 mm
Overall dimensions (w x d x h)
900 x 1680 x 2540 mm
Total weight (w / o fluids)
2000 kg
Electrode weight w. rot. head
15 kg
Electrode weight w / o rot. head
50 kg with man. safety
Rapid traverse speed X – Y
2 m / min
Dielectric fluid consumption
250 litres
Required cooling capacity
2.5 kW
Number of adjustable feet
3
T-slots: number / width / distance
4 slots / 10 mm / 3 x 100 mm
Flushing device
3 Pressure ports 1 Suction connection 1 Fine amount pressure port
